| 型号Model | 极限压力 Ultimate Pressure | 抽气速率Pumping Speed (L/s) | 进气口径 Inlet Diam (mm) | 排气口径 Outlet Diam (mm) | 最大允许压差 Max.permissible Diff.pressure | 转速 Speed(50/60Hz)RPM | 配用功率 Motor Power (kW) | 质量 Weight (kg) | |||
| Pa | Torr | (Pa) | (Torr ) | (Pa) | (Torr) | ||||||
| BZJP-70 | 5×10-2 | 3.7×10-4 | 70 | 80 | 80 | / | / | 8000 | 60 | 1.10 | 110 |
| BZJP-150A | 5×10-2 | 3.7×10-4 | 150 | 100 | 100 | / | / | 4000 | 30 | 2.20 | 190 |
| BZJP-300A | 5×10-2 | 3.7×10-4 | 300 | 150 | 150 | / | / | 4000 | 30 | 4.00 | 265 |
| BZJP-600A | 5×10-2 | 3.7×10-4 | 600 | 200 | 200 | / | / | 2700 | 20 | 7.50 | 570 |
| BZJP-1200C | 5×10-2 | 3.7×10-4 | 1200 | 250 | 200 | / | / | 2700 | 20 | 11.0 | 770 |
| BZJP-2500A | 5×10-2 | 3.7×10-4 | 2500 | 320 | 320 | / | / | 2700 | 20 | 18.5 | 1350 |
| BZJ-150A | 5×10-2 | 3.7×10-4 | 150 | 100 | 100 | 6700 | 50 | / | / | 2.20 | 180 |
| BZJ-300A | 5×10-2 | 3.7×10-4 | 300 | 150 | 150 | 5300 | 40 | / | / | 4.00 | 250 |
| BZJ-600A | 5×10-2 | 3.7×10-4 | 600 | 200 | 200 | 5300 | 40 | / | / | 7.50 | 550 |
| BZJ-1200C | 5×10-2 | 3.7×10-4 | 1200 | 250 | 200 | 4000 | 30 | / | / | 11.0 | 730 |
