瑞典 SKF 重载轴承,高刚度转子,确保稳定运行。
在恶劣的地形条件下仍可灵活移 动,压缩机配置吊环,要安全方便地进行吊装、运输。
宽敞的保养维修门,维护的零部件在可及范围之内,方便保养三滤、冷却器,减少停机时间。
型号 Model | 工作压力Working Pressure (Mpa) | 排气量Air Delivery (m³/min) | 外形尺寸 Dimensions(mm) | 电机功率 Moter Power (kw) | 出口管径 Outlet Pipe Diameter (inch) | 重量Weight (kg) | ||
长度(L) | 宽度(W) | 高度(H) | ||||||
BAEY-3.0/8G | 0.8 | 3 |
2750 |
1400 |
1300 |
18.5 |
2*G 3/4 |
800 |
BAEY-2.7/10A | 1.0 | 2.7 | ||||||
BAEY-2.3/13A | 1.3 | 2.3 | ||||||
BAEY-3.6/8G | 0.8 | 3.6 |
2750 |
1400 |
1300 |
22 |
2*G 3/4 |
900 |
BAEY-3.2/10A | 1.0 | 3.2 | ||||||
BAEY-2.7/13A | 1.3 | 2.7 | ||||||
BAEY-5.0/8A | 0.8 | 5 |
2800 |
1500 |
1500 |
30 | 1-G 3/4* 1-G1 1/4* |
1150 |
BAEY-4.5/10A | 1.0 | 4.5 | ||||||
BAEY-3.7/13A | 1.3 | 3.7 | ||||||
BAEY-6.0/8G | 0.8 | 6 | 3100 | 1500 | 1500 |
37 |
1-G 3/4* 1-G1 1/4* |
1200 |
BAEY-6.0/8A | 0.8 | 6 | ||||||
BAEY-5.6/10A | 1.0 | 5.6 | 2860 | 1500 | 1500 | |||
BAEY-4.8/13A | 1.3 | 4.8 | ||||||
BAEY-7.5/8G | 0.8 | 7.5 | 3100 | 1500 | 1500 |
45 |
1-G 3/4* 1-G1 1/4* |
1250 |
BAEY-7.5/8A | 0.8 | 7.5 |
2900 |
1520 |
1550 | |||
BAEY-6.9/10A | 1.0 | 6.9 | ||||||
BAEY-5.6/13A | 1.3 | 5.6 | ||||||
BAEY-10.0/8G | 0.8 | 10 |
3350 |
1680 |
1850 |
55 |
1-G 3/4* 1-G1 1/2* |
1450 |
BAEY-10.0/8A | 0.8 | 10 | ||||||
BAEY-8.7/10A | 1.0 | 8.7 | ||||||
BAEY-7.5/13A | 1.3 | 7.5 | ||||||
BAEY-13/8G | 0.8 | 13 | 3350 | 1650 | 2000 |
75 |
1-G 3/4* 1-G11/2* |
1800 |
BAEY-12/10G | 1.0 | 12 | 3350 | 1650 | 2000 | |||
BAEY-13/8A | 0.8 | 13 |
3500 |
1850 |
2000 | |||
BAEY-12/10A | 1.0 | 12 | ||||||
BAEY-10/13A | 1.3 | 10 | ||||||
BAEY-16/8G | 0.8 | 16 |
3500 |
1650 |
2000 |
90 | 1-G 1/4* 1-G1 1/2* |
2750 |
BAEY-13/10G | 1.0 | 13 | ||||||
BAEY-11.5/13G | 1.3 | 11.5 | ||||||
BAEY-20/8G | 0.8 | 20 |
3800 |
1750 |
2150 |
110 | 1-G2 1-4 3/4* |
3500 |
BAEY-16/10G | 1.0 | 16 | ||||||
BAEY-13.5/13G | 1.3 | 13.5 | ||||||
BAEY-22/8G | 0.8 | 22 |
3800 |
1700 |
2160 |
132 | 1-G 2 1-4 3/4* |
3600 |
BAEY-20/10G | 1.0 | 20 | ||||||
BAEY-17/13G | 1.3 | 17 | ||||||
BAEY-27/8G | 0.8 | 27 | 3910 | 1750 | 2200 |
160 | 1-G2 1-4 3/4* | 3800 |
BAEY-23/10G | 1.0 | 23 | 3850 | 1820 | 2240 | 3900 | ||
BAEY-20/13G | 1.3 | 20 | 3950 | 1800 | 2250 | 5000 | ||
BAEY-30/8G | 0.8 | 30 | 3870 | 1820 | 2200 |
185 |
1-G2 1-4 3/4* | 4600 |
BAEY-17/18G | 1.8 | 17 | 3860 | 1820 | 2250 |
4200 | ||
BAEY-19/17G | 1.7 | 19 | 3950 | 1820 | 2250 | |||
BAEY-21/13G | 1.3 | 21 | 3950 | 1820 | 2250 | |||
BAEY-35/8G | 0.8 | 35 | 3870 | 1800 | 2250 |
200 |
1-G2 1-4 3/4* |
4600 |
BAEY-30/10G | 1.0 | 30 | 3870 | 1820 | 2200 | |||
BAEY-22/17G | 1.7 | 22 | 3950 | 1820 | 2250 | |||
BAEY-27/13G | 1.3 | 27 | 4050 | 1950 | 2350 | 5000 | ||
BAEY-35/10G | 1.0 | 35 | 4120 | 1900 | 2390 | 250 |
1-G2 1-4 3/4* | 5200 |
BAEY-18/18G | 1.8 | 18 | 3990 | 1820 | 2310 | 160/4 级 | 4500 | |
BAEY-22/20G | 2.0 | 22 | 3990 | 1800 | 2310 | 200/4 级 | 4500 | |
BAEY-27/20G | 2.0 | 27 | 4120 | 1950 | 2390 | 250/4 级 | 5200 | |
BAEY-29/20G | 2.0 | 29 | 4100 | 1950 | 2390 | 280/4 级 | 5300 | |
BAEY-33/24G | 2.4 | 33 | 4200 | 2150 | 2500 | 315/4 级 | 5500 |
